2008 INDEX G250
Featured
2008 INDEX G250
or
Call 262-432-7474
Description
Has only cut aluminum since new
Specifications
| Manufacturer | INDEX |
| Model | G250 |
| Year | 2008 |
| Condition | Used |
| Stock Number | 064512 |
| Number of turrets | 3 |
| Tools per turret | 12 |
| Tooling | VDI-30 |
| Control | SIEMENS D |
| Machine weight | 29,768 lbs |
| Number of spindles | 2 |
| Maximum bar diameter | 90 mm |
| Maximum part length | 1,400 mm |
| Main spindle max. speed | 3,500 RPM |
| Counter spindle max. speed | 3,500 RPM |
| Live tools | Yes |
| VDI Tool Size | 30 |
| Total number of tools | 36 |
| Live tool max. speed | 6,000 rpm |
| C-Axis | Yes |
| Y-Axis | Turret 1 and 3 |
| B-Axis | Turret 1 and 3 |
| "W" serration turret | Yes |
| Material type | Blank |
| Steady rest | Yes |
| Oil or coolant | Coolant |
| Rigid tapping | Yes |
| HMI software version | 06.04.25.00 |
| Ejector or gantry | Gantry |
| Counter/sub spindle clamping mechanism | Jaws/collet/mandrel |
