VERTICAL MACHINING CENTERS RFM 600/2 SUBJECT TO AVAILABILITY, AND TERMS AND CONDITIONS FOLLOWING, WE OFFER FOR YOUR CONSIDERATION: One used 2004 RODERS RFM 600/2 High Speed Vertical Machining Center: Machine was made in Soltau, Germany -DESIGN CONCEPT- In the Roeders line of machines, accuracy, extreme dynamics and high machining speeds are combined with other important aspects such as outstanding chip removal, high flexibility, good ergonomics and the addition of automation. Features: -Patented sealing of all machine elements, therefore also ideally suitable for machining of graphite and other dust-creating abrasive materials without retooling, additional extraction equipment and other forms of restrictions. -Temperature stabilization of the complete machine frame for highly accurate production, water-cooling of bearings and spindle nuts as well as the milling spindle by means of an extra cooling sleeve. Integrated chip conveyance-simple disposal. -Accessibility of the work area is particularly easy from 2 sides and visibility is excellent. -Part loading with crane possible, front door opens roof. Tool changer is dust protected and with integrated laser measuring equipment. -Laser measuring equipment for length and diameter measuring as well as checking and profile determination of the milling tool in use. -Digital drives with Sercos interface. -2 encoder systems, with high resolution in each axis for greatest accuracy and dynamic response. Control technology, matched to the mechanical system of the machine, for movement completely free of contour variations. -Operational accuracy, depending on use, with the accuracy being restricted by the machining process and not the machine itself. -Workpiece probing with infrared 3D probe for fast setting up. -CONTROL- Roeders RMS6 CNC control with recent hardware & software upgrade V5.75 -WORKING RANGE- -FEED- -TABLE- -FISCHER SPINDLE- -TOOL MAGAZINE/CHANGER- -EQUIPPED WITH- Laser Tool Setter Preparation for dust extraction m&h Wireless Part Probe System 3R Robot Interface Spindle Chiller High Accuracy Spindle Compensation package -UPGRADES RECENTLY COMPLETED BY RODERS- 2 x new axis drives and power supply Hardware and software upgrade to Version 5.75 *System 3R Dynafix table chuck and pallet pictured are NOT included with the machine purchase!


ModelRFM 600/2
Stock Number064338
Number of axis3-Axis
Tool changer18 ATC
ControlRMS6 CNC V5.75
Spindle42,000 rpm
Spindle taperHSK-E40
X axis23.6"
Y axis17.7"
Z axis11.8"
Machine weightApproximately 11,440 lbs
Machine sizeApproximately 149" L-R X 67" F-B X 103" H
Traverse path x-axis (table travel)23.6"
Traverse path y-axis (saddle travel)17.7"
Traverse path z-axis (spindle head travel)11.8"
Maximum feed rate1,181 IPM
Table size27.5" x 21.6", T-slots
Table load capacity1,760 lbs
Spindle speeds42,000 rpm, oil-air lubrication, 19 HP
Number of tool stations18
