HERMLE C30U dynamic 5-Axis VMC 75 ATC

5-AXIS MACHINING CENTERS C30U dynamic Subject to availability, and terms and conditions of FRANKE CNC sales contract, we offer for your consideration: One used 2004/6 HERMLE C30U dynamic Full 5-Axis Simultaneous Gantry Style VMC May be inspected under power in our Wisconsin showroom by appointment. Machine was produced in the Black Forest at Maschinenfabrik Berthold Hermle AG-Gosheim, Germany in 10/2004. Sold as a demo machine and first installed new in the USA in 2006. HEIDENHAIN iTNC 530 CNC Control with hand-held electronic handwheel control unit TECHNICAL DATA: Machine equipped with external spindle chiller NC swivelling rotary table Fixture Table max swing…23”x23” (584 mm x 584 mm) not included Holding torque A-axis (dynamic)……………………..2,766 lb/ft (3,750 Nm) Clamping torque C-axis……………………………….2,213 lb/ft (3,000 Nm) T grooves in table………………………………………14 H7 (4 pcs-star type) Central boring…………………………………………Diameter 32 H7 DYNAMIC FEED DRIVE Feed force……………………………………………1,574 lb/ft (7,000 N) Rapid traverse………………………………………1,772 ipm (45 m/min) Acceleration……………………………………………236 inch/sec-2 (6 m/sec-2) Diameter and pitch of the feed spindles: X-axis 40/15 mm Y-axis 50/25 mm Z-axis 40/25 mm Tool change time approximately 5.5 seconds chip to chip EQUIPPED WITH: Mineral casting machine base Approximate machine weight 20,944 lb (9,500 kg) A axis dynamic HEIDENHAIN linear glass scales direct measuring in X/Y/Z Axes resolution 0.1 u HEIDENHAIN rotary encoders direct measuring in 4th and 5th Axes resolution 0.1 u Coolant tank unit Scraper chip conveyor Machine light Fully enclosed cabin enclosure Spindle air blast Orientation spindle stop M19 Helical interpolation Rigid tapping RS 232 port and Ethernet port RENISHAW infrared parts measuring touch probe BLUM laser tool measuring of tool length, diameter, and broken tool detection Electronic Temperature Compensation Leveling Shoes Ball Bar Test-at inspection Geometry Test-at inspection Spray pistol Adapter for oil mist extractor Electrical preparation for oil mist extractor Linear scale air protection PREP. CTS (HSKA63/18.000) Preparation for coolant thru the spindle Books, manuals and technical documentation on hand for the machine CONNECTION REQUIREMENTS: Purchase Point is Hartland, WI 53029 To the best of our knowledge all details listed above are deemed correct. It is the Buyer's responsibility to confirm all details and we encourage an inspection of the machine(s) and accessories prior to purchase.
