+GF+ MIKRON UCP 600 Vario

+GF+ MIKRON UCP 600 Vario

orCall +1 262-320-3399


5-AXIS MACHINING CENTERS UCP 600 Vario SUBJECT TO AVAILABILITY, AND TERMS AND CONDITIONS FOLLOWING, WE OFFER FOR YOUR CONSIDERATION: One used 2011 +GF+ MIKRON UCP 600 Vario Full 5-Axis Machining Center with 7 APC: Machine was made in Nidau, Switzerland Approximately 10,134 Spindle on hours total on fresh spindle Approximately 19,586 Program run hours total CONTROL Heidenhain iTNC 530 with Ethernet and electronic handwheel for part setup WORKING RANGE FEED DRIVE WORKING TABLE Maximum workpiece weight (automatic with pallet changer)    198 lbs (90 kg) Max pallet size possible for this machine    13.8" x 13.8" (350 x 350 mm) All feed motors are liquid-cooled Direct measuring system Heidenhain rotary encoders AUTOMATION WEIGHT STEPTEC SWISS MADE SPINDLE EQUIPPED WITH: Chip conveyor Spray gun Spindle chiller Direct measuring system Heidenhain glass scales X/Y/Z, Encoders B,C Completely enclosed machine cabin 18-70 bar (261 PSI-1,015 PSI) Coolant Thru the Spindle, w/paper band micro filter BLUM laser tool measuring of tool length and diameter M&H Infrared Parts Measuring Touch Probe


Manufacturer+GF+ MIKRON
ModelUCP 600 Vario
Stock Number064264
Number of axisFull 5-Axis
Tool changer60 ATC
ControlHH iTNC 530
Spindle20,000 rpm
Spindle taperHSK A63
X axis23.6" (600 mm)
Y axis17.7" (450 mm)
Z axis17.7" (450 mm)
Longitudinal x-axis23.6" (600 mm)
Cross y-axis17.7" (450 mm)
Vertical z-axis17.7" (450 mm)
B-axis (swivel)-115/+30 degrees
C-axis (rotary)n x 360 degrees
Feed rate x/y/z590 IPM (15 m/min)
Rapid speed x/y/z866 IPM (22 m/min)
Rapid speed b-axis (swivel)25 RPM
Rapid speed c-axis (rotary)33 RPM
Clamping surface13.8" x 13.8" (350 mm x 350 mm)
Maximum workpiece weight (manual loading)441 lbs (200 kg)
Pallet type this machine is equipped forSystem 3R Dynafix
Number of pallet stations this machine is equipped with7
Automatic tool changer60 positions
Blum laser tool measuring systemStandard
Infrared parts measuring touch probeM&H
Automatic pallet changer number of pallet stations7
Including pallet changerApproximately 16,976 lbs (7,700 kg)
Machine baseGranite
Spindle rpm20,000 RPM
Spindle power 40% ed40.2 HP (30 kW)
Spindle torque 40% ed67.1 Ft/Lb (91 Nm)
