+GF+ MIKRON Torque RTT UCP 600 Vario

+GF+ MIKRON Torque RTT UCP 600 Vario

orCall +1 262-320-3399


5-AXIS MACHINING CENTERS Torque RTT UCP 600 Vario SUBJECT TO AVAILABILITY, AND TERMS AND CONDITIONS FOLLOWING, WE OFFER FOR YOUR CONSIDERATION: One used +GF+ MIKRON Torque RTT UCP 600 Vario 5-Axis Machining Center: Machine was made in Nidau, Switzerland 2007; first installed new 5/2008 As of 8/2020 only 5,216 Program run and 4,979 Spindle on hours total ! CONTROL HEIDENHAIN iTNC 530 with Ethernet and electronic handwheel for part setup -With option Advanced Process System spindle vibration monitoring WORKING RANGE FEED DRIVE WORKING TABLE Clamping Surface    System 3R MacroMagnum 156 mm (6.14") diameter pallets Max workpiece size using tailstock    300mm (11.8") dia x 450mm (17.7") high Max workpiece size without tailstock    350mm (13.78")dia x 450mm (17.7")high All feed motors are liquid-cooled Direct measuring system HEIDENHAIN rotary encoders AUTOMATION WEIGHT STEPTEC SWISS MADE SPINDLE EQUIPPED WITH: Direct measuring system HEIDENHAIN glass scales X/Y/Z, Encoders B,C External spindle chiller Tool cleaning by air blast Pallet Changer MacroMagnum 156 Torque RTT torque motor direct drive rotary tilting table Tailstock for torque tilting table: The tailstock can be mounted on the rotary tilting table to support the machining of long and thin work pieces (such as aircraft blades and blisks). The max. distance between table and tailstock cone point is 450 mm (17.71"). The stroke of the tailstock is 350 mm (13.77"). The tailstock can be removed if larger work pieces are machined. 210 l (56 gallon) coolant tank with 2.5 bar (36.3 PSI) flood coolant Pump performance is 30l/min (7.93 gallon/minute)


Manufacturer+GF+ MIKRON
ModelTorque RTT UCP 600 Vario
Stock Number064335
Number of axisFull 5-Axis
Tool changer30 ATC
ControlHH iTNC 530
Spindle20,000 rpm
Spindle taperHSK A63
X axis23.6" (600 mm)
Y axis17.7" (450 mm)
B axis-101/+45 degrees
Z axis17.7" (450 mm)
C axis360 x 0.001 degrees
Longitudinal x-axis23.6" (600 mm)
Cross y-axis17.7" (450 mm)
Vertical z-axis17.7" (450 mm)
B-axis (swivel) range-101/+45 degrees
A-axis (rotary) rangen x 360 degrees
Feed rate x/y/z590 IPM (15 m/min)
Rapid speed x/y/z866 IPM (22 m/min)
Rapid speed b-axis (swivel)80 RPM
Rapid speed a-axis (rotary)200 RPM
Maximum workpiece weight176 lbs (80 kg)
Number of pallet stations this machine is equipped with16
Automatic tool changer30 positions
Blum laser tool measuring systemStandard, included
Infrared parts measuring touch probeM&H, included
Automatic pallet changer number of pallet stations16
Including pallet changerApproximately 16,976 lbs (7,700 kg)
Machine baseGranite
Spindle rpm20,000 RPM
Spindle power 40% ed40.2 HP (30 kW)
Spindle torque 40% ed67.1 Ft/Lb (91 Nm)
