5-AXIS MACHINING CENTERS HSM 600U SUBJECT TO AVAILABILITY, AND TERMS AND CONDITIONS FOLLOWING, WE OFFER FOR YOUR CONSIDERATION: One used 2011 MIKRON HSM600U 5-AXIS Machining Center with 7 X Pallet Chngr: Machine was manufactured in Nidau, Switzerland CONTROL Heidenhain iTNC 530 with Ethernet and electronic handwheel for part setup WORKING RANGE FEED DRIVE DIRECT DRIVE WORK TABLE Maximum workpiece weight (automatic with pallet changer)    198 lbs (90 kg) Max pallet size possible for this machine    13.8" x 13.8" (350 x 350 mm) Pallet type this machine is equipped with    System 3R Dynafix 280 x 280 mm NOTE optional pallets sized 350 x 350 mm NOT included with this machine With hydraulic clamping in turning and swivelling axis All feed motors are liquid-cooled Direct measuring system Heidenhain rotary encoders AUTOMATION WEIGHT SPINDLE EQUIPPED WITH: 153 gallon (580 l) coolant Tank with paper filtration system & 70 bar CTS Chip conveyor for higher demands Tool cleaning by air blast Direct measuring system Heidenhain glass scales X/Y/Z


Manufacturer+GF+ MIKRON
ModelHSM 600U
Stock Number064225
Number of axisFull 5-Axis
Tool changer50 ATC
ControlHH iTNC 530
Spindle24,000 rpm
Spindle taperHSK A63
X axis31.5" (800 mm)
Y axis23.6" (600 mm)
B axis+30/-110 degrees
Z axis19.7" (500 mm)
C axis360 x 0.001 degrees
Longitudinal x-axis31.5" (800 mm)
Cross y-axis23.6" (600 mm)
Vertical z-axis19.7" (500 mm)
B-axis (swivel)+30/-110 degrees
C-axis (rotary)n x 360 degrees
Number of simultaneous axis5/5 simultaneous
Feed rate x/y/z1,653 IPM (42 m/min)
Feed rate b-axis (swivel)200 RPM
Feed rate c-axis (rotary)360 RPM
Acceleration x/y/zup to 17 m/sec2
Pallet clamping surface11.02" x 11.02" (280 mm x 280 mm) pallets
Maximum workpiece weight (manual loading)264 lbs (120 kg)
Number of pallets this machine is equipped with7 pallets
Tool magazine automatic tool changer50 positions
Laser tool measuring systemStandard
Infrared parts measuring touch probeM&H
Automatic pallet changer number of pallets7 pallets
Including pallet changerApproximately 20,282 lbs (9,200 kg)
Machine basePolymer concrete (man made granite)
Spindle rpm24,000 RPM
Spindle power 40% ed29.5 HP (22 kW)
Spindle torque 40% ed33.9 Ft/Lb (46 Nm)
